DX2 Tension Meter |
|
A precise jeweled movement, choice of ball bearing mounted rollers and rugged cast aluminum housing makes the DX2 ideal for the toughest production floor application. Built-in mounting holes permit fixed installation for continuous in-line use. Built-in material thickness compensator maximizes accuracy when using filaments of different diameters. (Standard on model DX2-SP and higher ranges) |
|
|
|
Model |
Range |
Outer Roller Spacing c:c |
Calibration Material |
Thickness Compensator |
|
DX2-3 |
3-30 g |
38 mm |
PA: 0.12 mm Ø |
NA |
|
DX2-5 |
5-50 g |
38 mm |
PA: 0.12 mm Ø |
NA |
|
DX2-12 |
20-120 g |
38 mm |
PA: 0.12 mm Ø |
NA |
|
DX2-20 |
20-200 g |
38 mm |
PA: 0.12 mm Ø |
NA |
|
DX2-40 |
20-400 g |
38 mm |
PA: 0.20 mm Ø |
NA |
|
DX2-SP |
20-1000 g |
38 mm |
PA: 0.30 mm Ø |
Standard |
|
DX2-EX |
100-1000 g |
38 mm |
PA: 0.30 mm Ø |
Standard |
|
DX2-200 |
200-2000 g |
100 mm |
PA: 0.50 mm Ø |
Standard |
|
DX2-500 |
400-5000 g |
100 mm |
PA: 0.80 mm Ø |
Standard |
|
DX2-1K |
2-10 Kg |
100 mm |
PA: 1.00 mm Ø |
Standard |
|
DX2L-2K |
5-20 Kg |
150 mm |
PA: 1.50 mm Ø |
Standard |
|
DX2L-3K |
5-30 Kg |
250 mm |
|
Standard |
|
DX2L-5K |
5-50 Kg |
250 mm |
|
Standard |
|
Accuracy |
± 1% of full scale or ± 1 graduation mark on scale |
|
Diameter of Scale |
41 mm |
|
Maximum Speed |
2000 m/min (standard) 3500 m/min (K) 5000 m/min (HS) |
|
Outer roller distance, c:c |
DX2-5 to DX2-EX: 38 mm DX2-200 to DX2-1k: 100 mm DX2-2K: 150 mm DX2-3K to DX2-5K: 250 mm |
|
Roller Material |
Hard-coated aluminum (standard) Hardened steel (ST) Chromed Steel (w) Ceramic (CE) Plastic (PL) |
|
Housing Material |
Die-cast aluminum |
|
Dimensions |
225 x 90 x 44 mm (8.6" x 3.5" x 1.7") |
