司泰科的EM920关口表及电能质量装置在智能电网的使用使高级计量架构(AMI)进入了一个新的高度。
司泰科的EM920 eXpertmeter? 是一款美式圆形底座表,它是一款高端电能分析装置,拥有精确的测量和强大扩展功能。
EM920独具的插入式模块化设计使其具有强大的功能扩展性,把强大的智能、控制和通讯都加入到电表中。司泰科的插入式模块化理念也使您能方便的根据您的需求来配置产品。节省了时间和未来的替换成本,使其能快速,高性价比地响应市场的变化。
EM920 eXpertmeter? 是一款精度远超0.2s的高端关口表。它有大的长时间存储,用于记录负载/趋势曲线,高端电能质量分析,监测和记录事件和故障波形。.
EM920 eXpertmeter? 是MET认证的。
EM920 eXpertmeter? 系列用于电网间,电网和用户间。
可安装在目前没有或很少信息能获得的老变电站中,替换老的底座表,一旦安装,立刻能提供很多信息。 长期监测和存储能力能允许数月信息的存储。记录TOU复费率,负载曲线,最小/最大值,电能质量,故障/事件,定制化报告...这些信息对于计划和维护人员都很有用。 多重同时通讯允许通过MODBUS, DNP3.0, and MV90通讯,同时获得电能质量事件,比如骤升/骤降,瞬态监测等。 可本地查阅谐波情况,并用其独有的“方向性谐波”来判断问题原因。查看实时波形,判断电能质量。
三相多功能电力参数测量?xml:namespace>
<!--[if !supportLists]-->l <!--[endif]-->.? 电压,电流(包括中性线电流),功率,电能,功率因数,不平衡电压/电流,负荷曲线
多种电价计费表
<!--[if !supportLists]-->l <!--[endif]-->.? 0.05% 精确测量
<!--[if !supportLists]-->l <!--[endif]-->.? 0.2S 级的精度符合IEC 62053-22/ANSIC12.20
<!--[if !supportLists]-->l <!--[endif]-->.? 复费率分时电价(TOU)可满足任何计费要求 (四季,8 种电价)
<!--[if !supportLists]-->l <!--[endif]-->.? 独特的防破坏和防篡改功能
<!--[if !supportLists]-->l <!--[endif]-->.? 变压器和传输线损计算(8 点,PT 和 CT)
<!--[if !supportLists]-->l <!--[endif]-->.? 内建的精度自测
高级电能质量分析
<!--[if !supportLists]-->l <!--[endif]-->.? 电能质量分析符合 IEC 61000-4-30 A 类
<!--[if !supportLists]-->l <!--[endif]-->.? 内建 EN50160 统计和报告
<!--[if !supportLists]-->l <!--[endif]-->.? 备用电池和/或辅助电源,记录重大的电压跌落和电压中断
<!--[if !supportLists]-->l <!--[endif]-->.? 谐波和间谐波符合 IEC 61000-4-7 标准
<!--[if !supportLists]-->l <!--[endif]-->.? 定向电力谐波(通过PAS软件)
<!--[if !supportLists]-->l <!--[endif]-->.? 电压和电流总谐波畸变率 (THD)、电流总需量畸变率 (TDD)、k 系数
<!--[if !supportLists]-->l <!--[endif]-->.? 闪变测量符合 IEC 61000-4-15
<!--[if !supportLists]-->l <!--[endif]-->.? 波形记录,采样率高达 1024 次/周期
<!--[if !supportLists]-->l <!--[endif]-->.? 3 路电压和 4 路电流输入用于波形记录
<!--[if !supportLists]-->l <!--[endif]-->.? 电压跌落、电压浪涌和电压中断
<!--[if !supportLists]-->l <!--[endif]-->.? 故障记录
<!--[if !supportLists]-->l <!--[endif]-->.? 测量并记录到高达 50 A(10 倍于标称电流)的四个电流值
<!--[if !supportLists]-->l <!--[endif]-->.? ITI (CBEMA) 曲线(通过PAS软件)
瞬态记录仪
<!--[if !supportLists]-->l <!--[endif]-->.? 高速瞬态检测,快至 17 μs @ 60Hz / 20 μs @50Hz,1024个采样数/周波
<!--[if !supportLists]-->l <!--[endif]-->.? 对地瞬态值
<!--[if !supportLists]-->l <!--[endif]-->.? 测量高达 2 kV 的脉冲
事件/数据记录
<!--[if !supportLists]-->l <!--[endif]-->.? 与波形相关的电能质量事件
<!--[if !supportLists]-->l <!--[endif]-->.? 可记录超过 100 个带时间戳的参数
<!--[if !supportLists]-->l <!--[endif]-->.? 内置16M记录内存
<!--[if !supportLists]-->l <!--[endif]-->.? 时间同步 - IRIG-B (GPS) 或以太网 (SNTP)
其他特性
<!--[if !supportLists]-->l <!--[endif]-->.? 电介质承受度:6 kV(脉冲),4 kV AC @ 1 分钟
<!--[if !supportLists]-->l <!--[endif]-->.? 输入/输出和 ComPorts 隔离 - 4 kV AC
<!--[if !supportLists]-->l <!--[endif]-->.? 可选的远程显示模块 (RDM) LED 前面板显示屏
<!--[if !supportLists]-->l <!--[endif]-->.? 防篡改和自测功能
<!--[if !supportLists]-->l <!--[endif]-->内置红外端口
<!--[if !supportLists]-->l <!--[endif]-->Ethernet (100Mb/s), USB & RS232/485
<!--[if !supportLists]-->l <!--[endif]-->Modbus 主/从模式
<!--[if !supportLists]-->l <!--[endif]-->IRIG-B & RS232/485
<!--[if !supportLists]-->l <!--[endif]-->GSM/GPRS (Class 10)
<!--[if !supportLists]-->l <!--[endif]-->协议
<!--[if !supportLists]-->n <!--[endif]-->主/从Modbus Binary & ASCII
<!--[if !supportLists]-->n <!--[endif]-->Modbus RTU
<!--[if !supportLists]-->n <!--[endif]-->DNP 3.0
<!--[if !supportLists]-->n <!--[endif]-->TCP/IP
<!--[if !supportLists]-->n <!--[endif]-->IEC 61850 protocol
<!--[if !supportLists]-->n <!--[endif]-->IEC 62056-21/61
