| Item | Description |
 |
|
| Number of input channels | 8ch |
|
|
| Type of input terminal | BNC M3 Screw type terminal |
|
|
| Method | All channels isolated, Simultaneous sampling |
|
|
| Measurement range |
|
|
|
| Measurement range Voltage | 20mV to 500V / F.S. (Between + – terminals, 500 V p-p max.) |
|
|
| Measurement range Temperature |
Thermocouple: K, J, E, T, R, S, B, N, W(WRe5-26) |
|
|
| Measurement range Huity | 0 to 100% ( When using optional B-530 huity sensor is used ) |
|
|
| External Input | Trigger: 1ch, Selectable between pulse Logic: 4ch |
|
|
| External output | Alarm: 4ch |
|
|
| A / D converter | 16bit(out of which 14 are internally acknowledged) |
|
|
| Maximum sampling interval | 10 micro-second |
|
|
| Internal memory size | RAM：1 million data, 256MB Flash memory |
|
|
| External memory | USB memory (1 file 2 GB) |
|
|
| Calculation function | Statistics calculation, Searching function |
|
|
| Display | 5.7 inch TFT color LCD |
|
|
| Interface to PC | Ethernet ( 10BASE-T / 100BASE-TX ) , USB (Compatible with full speed) |
|
|
| Operating environment Temperature : | 0 to 40 ℃ (15 to 40 ℃ when operating by battery ) , Huity : 5～85 % R.H. |
|
|
| Power supply Battery pack : | 2 batteries installable |
|
|
| AC adapter | ( 100 to 240V AC ,50 to 60Hz ) , DC input ( 8.5 to 24V DC) |
|
|
| External dimensions (approx.) | 232W x 150H x 80D mm |
|
|
| Weight (approx.) | 1.1kg ( Excluding the AC adapter battery ) |
|
|
| Vibration resistance | Compatible with JIS Vibration testing methods for automobile Type 1 Class A-equivalent |
