Measuring items
Cell Voltage
Cell internal resistance
Inter-cell connection resistance
Negative post temperature
Measuring Range, Accuracy Resolution
No
Measuring items
Measuring Range
Accuracy
Resolution
1
Cell Voltage
0.1~60Vdc
±0.5%
10mV
2
Cell internal resistance
0.01~300mΩ
±1.0%
1uΩ
3
Inter-cell connection resistance
0.01~300mΩ
±1.0%
1uΩ
4
Negative post temperature
-20℃~80℃
±2.0%
0.1℃
Battery Capacity
5 ~ 6,000 Ah
Character
User-friendly design applying 3.2" TFT LCD
Slim design, the first of its kind in the world
Integrated data storage with USB serial port
Charging Ripple Current percent(%) FFT analysis
Adopt SD memory card
